M8 Nylon Locknut (21)Ð8
M8 Split Washer (49)Ð4
M10 Split Washer (41)Ð5
M8 x 90mm Carriage Bolt (30)Ð4
M10 x 25mm Button Screw (8)Ð5
M4 x 16mm Screw (9)Ð1
M4 x 12mm Console Screw (4)Ð4
PART IDENTIFICATION CHART
Use the chart below for help identifying the small
parts used in assembly. The number in parenthesis
below each part refers to the key number of the part.
The second number refers to the quantity used in
assembly. Note: Some parts may have been pre-
attached for shipping purposes. If a part is not
found in the parts bag, check to see if it has been
pre-attached.
