12
8
73
7
7
72
69
69
1
6
6
1
8. Attach a Handrail (69) to the Left Upright (72)
with two 5/16" x 3 1/4" Screws (1), two 5/16" Star
Washers (6), and a #8 x 3/4" Screw (7); start all
three Screws, and then tighten them.
Attach the other Handrail (69) to the Right
Upright (73) in the same way.
9
9. Set the Console Base (84) facedown on a soft
surface to avoid scratching the Console Base.
Attach the Left and Right Trays (86, 87) to the
Console Base (84) with six #8 x 3/4" Screws (7);
start all six Screws, and then tighten them.
Do not overtighten the Screws.
Then, remove and save the four 5/16" x 5/8"
Screws (2).
7
87
86
84
7
7
7
2
7
7
2
To Next Page
