9
12
12
8
2
48
81
2. Make sure that the power cord is unplugged.
With the help of a second person, carefully tip
the treadmill onto one side. Partially fold the
Frame (48) to help stabilize the treadmill.
Next, attach the four Base Pads (12) to the
bottom of the Upright Base (81) with four #8 x 1"
Tek Screws (8). Do not overtighten the Tek
Screws.
Then, tip the treadmill so that the Upright Base
(81) is resting on the floor as shown in step 3.
8
3
3. Remove any ties securing the Upright Wire (74)
to the Upright Base (81).
Next, identify the Right Upright (73). Have a
second person hold the Right Upright near the
Upright Base (81).
See the inset drawing. Tie the wire tie (A) in
the Right Upright (73) securely around the end
of the Upright Wire (74). Then, insert the Upright
Wire into the lower end of the Right Upright and
pull the upper end of the wire tie until the Upright
Wire is routed through the Right Upright.
81
73
74
73
74
A
A
74
12
8
12
8
To Next Page
