8.Packaging list
No. Name
Unit
Qty
Remark
1
2
3
4
pcs
pcs
pcs
pcs
1
1
1
1
Charging equipment
User manual
QC certificate
9.Annex
8.1 Electrical diagram
Fig8-1. 3-phase AC charging equipment main circuit
AC SPD
AC KM
INPUT
OUTPUT
AC Charge
Gun
Cable holder
DANGER
Notice:
1.Wiring and installation must be carried out by qualified personnel, phase
sequence cannot be connected incorrectly!
2.The PE wire should be grounded firmly!
3.No live working! The incoming power should be cut off before opening the
charging equipment.
4.Unqualified person is not allowed to open or repair!
