66
SPECIFICATIONS
P/No. IC1500L
Type 5 stage
Input (Nominal) 240VAC, 50Hz
Input Power 240W
Output Voltage 12V
Output Current 2, 4, 8, 15A
Minimum Start Voltage 2.0V
Back Drain 1mA (2mA with remote)
CHARGE CONTROL
Soft Start 1 Charge at 5% of set current, until the battery reaches 8.0V
Soft Start 2 Charge at 25% of set current, until the battery reaches 10.0V
Bulk Set current up to 14.5V
Absorption Constant voltage of 14.5V until current drops to the following set points:
2 Amp – 0.2A
4 Amp – 0.4A
8 Amp – 0.8A
15 Amp – 1.5A
Float 13.5V
POWER SUPPLY
Set Voltage 13.8V
Maximum Current 15A
BATTERY RANGE
Deep Cycle 4–150Ah
Types of Batteries Lithium Iron Phosphate
Size (mm) 222 x 61 x 108
Weight 1.54 kg
