Projecta IC2500 User Manual

19
SPECIFICATIONS
P/No. IC2500 & IC2500W IC3500 IC5000 IC800-24
Type 7stage 7stage 7stage 7stage
Input(nominal) 240VAC,50Hz 240VAC,50Hz 240VAC,50Hz 240VAC,50Hz
InputPower 792W 1080W 1488W 480W
OutputVoltage 12V 12V 12V 24V
OutputCurrent 2,6,12,25A 2,8,16,35A 2,6,12,25,50A 2,4,6,8A
MinimumStartVoltage 2.5V 2.5V 2.5V 4.5V
BackDrain 1mA 1mA 1mA 1mA
CHARGE CONTROL
Desulphation Highfrequency Highfrequency Highfrequency Highfrequency
Pulse charge Pulse charge Pulse charge Pulse charge
upto11V upto11V upto11V upto22V
SoftStart Halftheratedset Halftheratedset Halftheratedset Halftheratedset
currentupto12V currentupto12V currentupto12V currentupto24V
Bulk Setcurrentupto: Setcurrentupto: Setcurrentupto: Setcurrentupto:
14.1V(GEL), 14.1V(GEL), 14.1V(GEL), 28.2V(GEL),
14.4V(AGM), 14.4V(AGM), 14.4V(AGM), 28.8V(AGM),
14.7V(WET), 14.7V(WET), 14.7V(WET), 29.4V(WET),
14.7V(CALCIUM) 14.7V(CALCIUM) 14.7V(CALCIUM) 29.4V(CALCIUM)
Absorption Constantvoltageuntilcurrentdropstothefollowingsetpoints:
2Ampsetting:0.3A 2Ampsetting:0.3A 2Ampsetting:0.3A 2Ampsetting:0.3A
6Ampsetting:0.9A 8Ampsetting:1.2A 6Ampsetting:0.9A 4Ampsetting:0.6A
12Ampsetting:1.8A 16Ampsetting:2.4A 12Ampsetting:1.8A 6Ampsetting:0.9A
25Ampsetting:3.75A 35Ampsetting:5.25A 25Ampsetting:3.75A 8Ampsetting:1.2A
  50Ampsetting:7.5A
Equalization Constantcurrent Constantcurrent Constantcurrent Constantcurrent
(Calciummodeonly) (2.0–3.75A)upto16V (2.0–5.25A)upto16V (2.0–7.5A)upto16V (2.0A)upto32V
thenholdfor1hour thenholdfor1hour thenholdfor1hour thenholdfor1hour
or12hourtimeout or12hourtimeout or12hourtimeout or12hourtimeout
Analysis Monitorsbatteryfor90sec
Recondition Constantcurrent Constantcurrent Constantcurrent Constantcurrent
(0.3–3.75A)for (0.3–5.25A)for (0.3–7.5A)for (0.3–1.2A)for
4hourslimitedto: 4hourslimitedto: 4hourslimitedto: 4hourslimitedto:
14.1V(GEL), 14.1V(GEL), 14.1V(GEL), 28.2V(GEL),
14.4V(AGM), 14.4V(AGM), 14.4V(AGM), 28.8V(AGM),
16.0V(WET), 16.0V(WET), 16.0V(WET), 32.0V(WET),
16.0V(CALCIUM) 16.0V(CALCIUM) 16.0V(CALCIUM) 32.0V(CALCIUM)
Float 13.7V 13.7V 13.7V 27.4V
POWER SUPPLY
SetVoltage 13.8V 13.8 13.8V 27.6V
MaximumCurrent 25A 35A 50A 8A
BATTERY RANGE
DeepCycle 14–500Ah 14–700Ah 14–1000Ah 14–160Ah
Automotive 80–3000CCA 80–4200CCA 80–6000CCA 80–1000CCA
Marine 110–4200MCA 110–5800MCA 110–8300MCA 110–1300MCA
TypesofBatteries MosttypesofbatteriesincludingGEL,AGM,WETCELLandCALCIUM
Size(mm) IC2500: 210x81x168 250x81x168 270x81x168 190x81x168
IC2500W: 218x86x174
Weight IC2500: 2.0kg 2.6kg 3.0kg 1.8kg
IC2500W: 2.0kg
