7
MOUNTING REMOTE CONTROL
FLUSH MOUNT
•Cuta93mmx70mmholeintothedesiredmountingsurfacetosuitthesupplied
mounting plate.
•Positionthemountingplateintotheholewiththesidelabelled‘FLUSHMOUNT’
facingoutwardsandscrewthesuppliedscrewsintothemountingsurfaceasper
thebelowillustration.
•Cliptheremotecontrolintothemountingbracket.
SURFACE MOUNT
•Positionthesuppliedmountingplateontothedesiredmountingsurfacesotheside
labelled‘SURFACEMOUNT’isfacingoutwardsandscrewthesuppliedscrewsinto
themountingsurfaceasperthebelowillustration.
•Drilla15mmcableexitholeintothemountingsurface,ensurecableexitholeis
positioned directly in the middle of the mounting plate.
•Positiontheremotecontrolintotheremotecontrolsurroundasperthebelow
illustration and clip into the mounting bracket.
BULK
CHARGE
POWER ON
FULLY
CHARGED
RECON
CHARGE
BAT TYPE
VOLT/AMP
ABSORB
BULK
CHARGE
POWER ON
FULLY
CHARGED
RECON
CHARGE
BAT TYPE
VOLT/AMP
ABSORB
F L U S H M O U N T
F L U S H M O U N T
S U R F A C E M O U N T
BULK
CHARGE
POWER ON
FULLY
CHARGED
RECON
CHARGE
BAT TYPE
VOLT/AMP
ABSORB
BULK
CHARGE
POWER ON
FULLY
CHARGED
RECON
CHARGE
BAT TYPE
VOLT/AMP
ABSORB
F L U S H M O U N T
F L U S H M O U N T
S U R FA CE MO U N T
