P/No. IC25, IC25W, IC25RV IC35 IC50 IC8-24
CHARGE CONTROL – 7 STAGE
Desulphation High frequency High frequency High frequency High frequency
Pulse charge Pulse charge Pulse charge Pulse charge
up to 11V up to 11V up to 11V up to 22V
Soft Start Half the rated set Half the rated set Half the rated set Half the rated set
current up to 12V current up to 12V current up to 12V current up to 24V
Bulk Set current up to: Set current up to: Set current up to: Set current up to:
14.1V (GEL), 14.1V (GEL), 14.1V (GEL), 28.2V (GEL),
14.4V (AGM), 14.4V (AGM), 14.4V (AGM), 28.8V (AGM),
14.7V (WET), 14.7V (WET), 14.7V (WET), 29.4V (WET),
14.7V (CALCIUM) 14.7V (CALCIUM) 14.7V (CALCIUM) 29.4V (CALCIUM)
Absorption Constant voltage until current drops to the following set points:
2 Amp setting: 0.3A 2 Amp setting: 0.3A 2 Amp setting: 0.3A 2 Amp setting: 0.3A
6 Amp setting: 0.9A 8 Amp setting: 1.2A 6 Amp setting: 0.9A 4 Amp setting: 0.6A
12 Amp setting: 1.8A 16 Amp setting: 2.4A 12 Amp setting: 1.8A 6 Amp setting: 0.9A
25 Amp setting: 3.75A 35 Amp setting: 5.25A 25 Amp setting: 3.75A 8 Amp setting: 1.2A
50 Amp setting: 7.5A
Equalization Constant current Constant current Constant current Constant current
(Calcium mode only) (2.0–3.75A) up to 16V (2.0–5.25A) up to 16V (2.0–7.5A) up to 16V (2.0A) up to 32V
then hold for 1 hour then hold for 1 hour then hold for 1 hour then hold for 1 hour
or 12 hour timeout or 12 hour timeout or 12 hour timeout or 12 hour timeout
Analysis Monitors battery for 90 sec
Recondition Constant current Constant current Constant current Constant current
(0.3–3.75A) for (0.3–5.25A) for (0.3–7.5A) for (0.3–1.2A) for
4 hours limited to: 4 hours limited to: 4 hours limited to: 4 hours limited to:
14.1V (GEL), 14.1V (GEL), 14.1V (GEL), 28.2V (GEL),
14.4V (AGM), 14.4V (AGM), 14.4V (AGM), 28.8V (AGM),
16.0V (WET), 16.0V (WET), 16.0V (WET), 32.0V (WET),
16.0V (CALCIUM) 16.0V (CALCIUM) 16.0V (CALCIUM) 32.0V (CALCIUM)
Float 13.7V 13.7V 13.7V 27.4V
CHARGE CONTROL – 5 STAGE LITHIUM
Soft Start 1 Charge at 5% of set current, until the battery reaches 8.0V
Soft Start 2 Charge at 25% of set current, until the battery reached 10.0V
Bulk Set rate of current, up to 14.2V
Absorption 10% of the set rate of current
Float 13.5V
BATTERY RANGE
Automotive 80–3000CCA 80–4200CCA 80–6000CCA 80–1000CCA
Marine 110–4200MCA 110–5800MCA 110–8300MCA 110–1300MCA
Deep Cycle 14–500Ah 14–700Ah 14–1000Ah 14–160Ah
Lithium 4–250Ah 4–350Ah 4–500Ah 8–200Ah
Types of Batteries Lithium, GEL, AGM, WET, CALCIUM
Size (mm) IC25: 210 x 81 x 168 250 x 81 x 168 270 x 81 x 168 190 x 81 x 168
IC25W: 218 x 86 x 174
Weight IC25: 2.0 kg 2.6 kg 3.0 kg 1.8 kg
IC25W: 2.0 kg
19
