Projecta IntelliJay PM300-BTJ User Manual

12
4. WIRING
4.1 Material
CODE NAME MODEL/
LENGTH
QTY P/No. ON
DRAWING
1 Transformer Unit PM335J 1 1
2 LCD Monitor PMLCD-BTJ 1 2
3 Fresh water tank 1 level sensor Not included
and to be
ordered
separately
0 4
4 Fresh water tank 1 level sensor 0 5
5 Tap water tank level sensor 0 6
6 Waste water tank level sensor 0 7
7 Solar 0 9
10 Communication line (RS485) 10m 1 PMLCDC-10
11 Temperature line 5m 1 PMTS
12 Battery sensor line 3m 1 PMBS
13 Water tank probe line
Not included
0
PMWS200 /
PMWS400
14 Water tank probe line 0
15 Water tank probe line 0
16 Water tank probe line 0
17 Power Cable 1.5m 1 PMAC
Table 4 Component List of PM300-BTJ
1
4 5 6 7
2
PMLCDC
PMAC
PMTS PMBS
PMWS200/
PMWS400
PMWS200/
PMWS400
PMWS200/
PMWS400
PMWS200/
PMWS400
9
PM335J
Monitor
Solar
Outdoor
Temperature Sensor
Battery Temperature
Sensor and Terminal
Voltage
AC in
240V / 50Hz
~
L
N
BM COM
House Battery –
House Battery +
House Battery
(12VDC)
Vehicle Battery –
Vehicle Battery +
Vehicle Battery
(12VDC)
Solar–
Solar+
Solar in
Vmp: 17– 50V
Fresh Water
Tank 1
Level Sensor
Fresh Water
Tank 2
Level Sensor
Tap Water
Tank
Level Sensor
Waste Water
Tank
Level Sensor
N L
AC IN
Monitor Switch
Panel
Battery
Sensor
Waste
Water
Tank
Tap
Water
Tank
Fresh
Water
Tank 2
Fresh
Water
Tank 1
•
L12
•
L13
•
L14
L14
•
L13 •
L12 •
L11 •
L10 •
L9 •
L8 •
L7 •
L6 •
L5 •
L4 •
L3 •
L2 •
L1 •
Solar
• •
Remote
Isolation
Switch
House
Batt -
House
Batt +
Vehicle
Batt -
Vehicle
Batt +
L11 L10 L9 L8 L7 L6 L5 L4 L3 L2 L1
• • • • • • • • • • •
CF / Spare
Awning
Slide Out
Always ON
Spare
Spare
Light 1
Light 2
Light 3
12V
12V
12V
HWS
Pump
PWR Isolation Switch
