3.2 LCD Monitor

(PM300-BTJ only)

Figure 11 Dimension of Monitor PMLCD-BTJ (Unit:mm)

Installation:

PM335J can be installed on a horizontal surface or vertically on a wall. Please see following instructions:

Figure 10 Installation of PM335J (Unit: mm)

Ensure clearance on both sides of PM335J unit

upon installation. A recommended clearance of

5cm on each side.

Figure 9 Dimension of PM335J (Unit: mm)

164

264

300

128
