ProLights Diamond19 - Page 21

21
DIAMOND19
STAND EXT-1 EXT-2 BAS-8 BAS-16
FUNCTION DMX
Value
19 Ch 32 Ch 98 Ch 14 Ch 16 Ch
4 6
No function (shutter open)
Pulse-eect in sequences
No function (shutter open)
Random strobe eect slow to fast
No function (shutter open)
096 - 127
128 - 159
160 - 191
192 - 223
224 - 255
6 9 9 5 7
DIMMER
Dimmer (close to open) 000 - 255
7 10 10 6 8
VIRTUAL COLOR FUNCTION
On Function
CTC Function
Forward Spin
Reverse Spin
Continuous
Color Bounce
TBD
000 - 015
016 - 031
032 - 047
048 - 063
064 - 079
080 - 111
112 - 255
8 11 11 7 9
VIRTUAL COLOR 1
CTC Function
Color Temperature Correction 2000K->2700K
White 3200K
White 4200K
White 5600K
White 8000K
Forward Spin
Rainbow Eect (Slow to Fast)
Reverse Spin
Rainbow Eect (Slow to Fast)
Continuous & Color Bounce
Black
Red
Green
Blue
White
Red=0, Green->up, Blue=full, White=0
Red=0, Green=full, Blue->down, White=0
Red->up, Green=full, Blue=0, White=0
Red=full, Green->down, Blue=0, White=0
Red=full, Green=0, Blue->up, White=0
Red->down, Green=0, Blue=full, White=0
000 - 223
224 - 231
232 - 239
240 - 247
248 - 255
000 - 255
000 - 255
000 - 000
001 - 001
002 - 002
003 - 003
004 - 004
005 - 046
047 - 088
089 - 130
131 - 172
173 - 214
215 - 255
9 12 12 8 10
VIRTUAL COLOR 2 (Only on Color Bounce)
Color Bounce
Black
Red
000 - 000
001 - 001
