DIAMOND19
18
3.15 DMX CONTROL
STAND EXT-1 EXT-2 BAS-8 BAS-16
FUNCTION DMX
Value
19 Ch 32 Ch 98 Ch 18 Ch 20 Ch
1 1 1 1 1
PAN
0~100% 000 - 255
2 2 2
PAN FINE
0~100% 000 - 255
2 3 3 2 3
TILT
0~100% 000 - 255
4 4 4
TILT FINE
0~100% 000 - 255
3 5 5 3 5
MOVEMENT SPEED
Fast to slow 000 - 255
6 6
MOVEMENT FUNCTION
Normal
Movement with backout
TBD
000 - 015
016 - 031
032 - 255
4 7 7
SHUTTER FUNCTION
Normal Shutter Functions
Pulse-eect Forward
Pulse-eect Reverse
Random strobe
TBD
000 - 015
016 - 031
032 - 047
048 - 063
064 - 255
5 8 8
SHUTTER
Normal Shutter Functions
Close
Strobe Rate (slow to fast)
Open
Pulse-eect Forward
Close
Strobe Rate (slow to fast)
Open
Pulse-eect Reverse
Close
Strobe Rate (slow to fast)
Open
Random Strobe
Close
Strobe Rate (slow to fast)
Open
000 - 031
032 - 223
224 - 255
000 - 031
032 - 223
224 - 255
000 - 031
032 - 223
224 - 255
000 - 031
032 - 223
224 - 255
4 6
SHUTTER
Shutter closed
No function (shutter open)
Strobe eect slow to fast
000 - 031
032 - 063
064 - 095
