ProLights Diamond19 - Wireless Control Settings; Fixture Settings

21
DIAMOND19
STAND EXT-1 EXT-2 BAS-8 BAS-16
FUNCTION DMX
Value
19 Ch 32 Ch 98 Ch 14 Ch 16 Ch
22
Bit4=LED2 Red Switch
Bit5=LED2 Green Switch
Bit6=LED2 Blue Switch
Bit7=LED2 White Switch
000 - 016
000 - 032
000 - 064
000 - 128
23
PATTERN BYTE 2
Direct access to Pattern of LED3 & LED4 000 - 255
24
PATTERN BYTE 3
Direct access to Pattern of LED5 & LED6 000 - 255
25
PATTERN BYTE 4
Direct access to Pattern of LED7 & LED8 000 - 255
26
PATTERN BYTE 5
Direct access to Pattern of LED9 & LED10 000 - 255
27
PATTERN BYTE 6
Direct access to Pattern of LED11 & LED12 000 - 255
28
PATTERN BYTE 7
Direct access to Pattern of LED13 & LED14 000 - 255
29
PATTERN BYTE 8
Direct access to Pattern of LED15 & LED16 000 - 255
30
PATTERN BYTE 9
Direct access to Pattern of LED17 & LED18 000 - 255
31
PATTERN BYTE 10
Direct access to Pattern of LED19 000 - 255
22
RED PIXEL 1
LED O
LED On
000 - 127
128 - 255
23
GREEN PIXEL 1
LED O
LED On
000 - 127
128 - 255
24
BLUE PIXEL 1
LED O
LED On
000 - 127
128 - 255
25
WHITE PIXEL 1
LED O
LED On
000 - 127
128 - 255
... ....
94
RED PIXEL 19
LED O
LED On
000 - 127
128 - 255
