INSTALLATION
The diagram below determines the correct dimensions to install
the oven in a cabinet. This oven can also be installed as an under
counter oven.
Securing the oven to the counter
1. Fit the oven into the counter recess.
2. Open the oven door.
3. Secure the oven to the counter with
two holders (A) which fit the holes in
the oven frame and fit the two screws
(B).
WARNING: In order to ensure adequate
ventilation, ensure that there
are air inlets and outlets for
ventilating the interior of the
counter adequately.
575
595
560
600
850
50
80
250
100
570
600
560
mm
595
mm
mm
mm
mm
mm
mm
mm
mm
mm
mm
mm
mm
