// SPÉCIFICATIONS TECHNIQUES
Suspension Leverage Ratio
0
3,0
2,8
2,6
2,9
2,7
2,5
2,4
2,3
20 40 60 80 100 120 140
Synthetic silicon
based grease
Synthetic silicon
based grease
Torque: 15Nm
Loctite 243
Torque: 15Nm
Loctite 243
Torque: 15Nm
Loctite 243
Torque: 15Nm
Loctite 243
Torque: 15Nm
Loctite 243
Torque: 15Nm
Loctite 243
7
8
9
10
6
11
18
4
12
13
14
15
16
23
17
5
20
21
22
19
3
2
24
1
Torque: 12Nm
HUGENE - Standards
Shock length 210mm
Shock travel 50mm
Shock mount top 8mm x 30mm
Shock mount bottom 8mm x 30mm
Rear wheel travel 140mm
Bottom bracket BSA 73mm
Brake mount Post mount 180mm
Seat post diameter 31,6mm
Head set (S.H.I.S.) Top: IS42 / Bottom: IS52
Rear wheel axle x12 (148 mm-Boost)
Rear hub width 148mm (Boost)
Chain line 52 mm (boost)
Chain guide mount ISCG 05
Tire size 29" x 2,35
Maxium fork travel 140-150mm
Hanger SRAM UDH
