ProScan PDVD1034 - Power Source; AC;DC Adapter Charging Procedure; Car Adapter Charging Procedure

Charging by supplied AC/DC adapter:
1. ConnecttheplugfromthesuppliedAC/DCadaptertotheDCINJackonthemain
unit.
2. ConnecttheAC/DCadaptertothewalloutlethavingAC100-240V~;50/60Hz.
Notes:
• TheAC/DCadapterisintendedtobecorrectlyorientedinaverticaloroormount
position.
• Yourbatterywilllastlongerifyoufollowthesesimpleguidelinesforcaringforand
storing it.
• Forrsttimecharge,chargeitapproximately12hours.Fornormalcharge,itneeds
approximately6hours.
• Rechargeandstorethedevicewithinthetemperaturerangeof5°C~35°C(40°F~95°F).
• Donotovercharge(longerthan24hours).Excessivechargingordischargingmay
shorten the battery’s life.
• Batterylifenaturallyshortensslowlyovertime.
Charging by the supplied Car Adapter:
1. Connect to the cigarette lighter socket of a vehicle that has a 12V battery as the figure
below.ItisNOTcompatiblewithavehiclethathasa24Vbattery.
2. Thisisaspecialnegativegroundedcaradapter.Usingthiscaradapterwithapositive
grounded car can cause a malfunction.
3. DoNOTpluginthecaradapteruntilthecarignitionisturnedon.
4. Disconnect the car adapter from the cigarette lighter and the unit after use.
Power Source
Tothecigarette
lighter socket
ToDCINJackonthemainunit
11
Theunithasabuilt-inDC 7.4V1900mAhLithium-ionrechargeablebattery.Rechargeit
as follows:
