ProScan PDVD1034 - Connecting the Main Unit to the Secondary Unit

Making Connections
2. Connecting the main unit to the secondary unit.
DCtoDCcable
(included)
3.5mm audio/video cable
(included)
Note:Thesecondaryunitmustbe
connected to the main unit, it can
not be operated independantly.
SECONDARY UNIT:MAIN UNIT:
PHONE AV OUT
USBSD/MMC CARD
DC OUT
DC IN
13
DC IN
AV IN PHONE POWER
OFF ON
