Proscend 5200N Series User Manual

G.SHDSL .bis Router User Manual V0.04
33
Filter Configuration
Item Description
Active Activate the classifier
Name Enter the name of the classifier
Interface Select from WAN or from LAN for the traffic of the classifier
Priority Assign priority to the traffic of the classifier
Order Ordering number of the classifier
Click on Apply to save the parameters or Cancel to start configuring this page from beginning.
4
4
.
.
3
3
.
.
8
8
R
R
I
I
P
P
RIP (Routing Information Protocol) allows one router to exchange routing information with another.
ADVANCED>RIP
Click Modify to edit each entry information
RIP>Entry Config
Entry Config
Item Description
Direction Select Directions from:
Off: No RIP packets will be sent, and incoming RIP packets will be ignored
Both: Routing table will be broadcasted periodically and incorporated
received information from both direction
In Only: Only RIP information received will be incorporated
Out Only: Only broadcast device’s routing table periodically
