1. INTRODUCTION
The instrument is a stable and high performance True-RMS digital multimeter
driven by battery. With 25mm high LCD display, the digital multimeter is easier
for users to read the digits. In addition, the design of backlight and overload
protection is convenient for operation.
The function of MT-1710 is to measure DCV, ACV, DCA, ACA, Resistance,
Capacitance, Frequency, Temperature, Transistor, Diode and Continuity test.
The instrument which adopts dual-integral A/D converter is an excellent meter.
It’s an ideal tool for lab, factory and field use.
2. SAFETY NOTES
The meter meets the standard of IEC1010. Please read safety notes before
operation.
1．Do not input more than the limited voltage of 1000V DC or 750V AC RMS
when measuring voltage.
2．Safety voltage is less than 36V. When the voltage is higher than 36V DC,
25V AC, please check the connection, insulation of test leads to avoid
electric shock.
3．When switching function and range, test probes should be removed from
testing point.
4．Select correct function and range.
5．To measure current, do not input over 10A current.
6．Safety symbols:
“
” High Voltage
“
” GND
“
” Dual Insulation
“
” Refer to Manual
“
” Low Battery
3. SPECIFICATIONS
3.1 General Specifications
Display Mode: LCD display
Max. Indication: 3999 (3 3/4), auto polarity indication
Measuring Method: Dual-slope integrating A/D converter system
Sampling Rate: Approx. 3 times/second
Over Range Indication: “OL”
Low Battery: “
”
Operating Environment: Temperature (0 ~ 40)
℃, Humidity<80%RH
Power: 9V battery.
Dimension: 190mm×95mm×45mm.
Weight: Approx 370g. (Not included battery)
Accessories: Operation manual, holster, gift box, thermocouple, test
leads
1
