Capacitance：
Range Accuracy Resolution
10nF ±(5.0%+20) 10pF
100nF 100pF
1u F 1nF
10uF 10nF
100uF
±(3.5%+8)
100nF
1mF/10mF/100 mF ±(5.0%+10) 1 uF/10 uF/100 uF
Overload Protection: 250V DC/AC peak value
Frequency：
Range Accuracy Resolution
100Hz 0.01Hz
1000Hz 0.1Hz
10kHz 1Hz
100kHz 10Hz
1MHz 100Hz
30MHz
±(0.5%+10)
1kHz
Input Sensitivity: 1.5V
Overload Protection: 250V DC/AC peak value
hFE test：
Range Value Test condition
NPN or PNP 0~1000
Basic current is approx.
10uA,Vce is approx.3V
Warning: do not input voltage at the range for safety
Diode and continuity Test：
Range Value Test Condition
Positive voltage drop
of diode
The positive DC Current is
approx.0.5mA; negative
voltage is approx. 1.5V.
Buzzer sounds, the
resistance is less
than 40±30Ω.
Open circuit voltage:
0.5V
Overload Protection: 250V DC/AC peak value
Warning: do not input voltage at the range for safety.
