ASSEMBLY INSTRUCTIONS
STEP 1
Slide two rubber caps into
each base with the longest
side on the bottom.
STEP 2
Align the holes at the bottom
of the holder with the holes
on the base. Place a thick
washer on 4 screws and insert
through the aligned holes.
Place a skinny washer on the
end of the screw and then
screw on the nut. To tighten,
place one wrench around the
screwhead to hold and use
the other to tighten the nut.
STEP 3
Place the connecting rail
between both holders and
align the holes. Place a thick
washer on 4 screws and
place them in each hole.
Place a skinny washer on the
end of the screw and then
screw on the nut. Completely
tighten with the wrenches
provided.
STEP 4
Slide the handle bars into
the holders. Then align the
holes in the handle bars and
holders to screw in the lock
pin screw.
