36 OPTIMAX
®
Spare Parts List
®
Pos. Order No. Description
Mammography Processor
- 1171-0-0600 Roller rack, dryer
Graphic Arts Processor
- 1172-0-0300 Roller rack, developer
- 1172-0-0600 Roller rack, dryer
Standard Processor
- 1170-0-0300 Roller rack, developer
- 1170-0-0400 Roller rack, fixer
- 1170-0-0600 Roller rack, dryer
100 0170-0-0301 Side plate dev. w. shafts (left)
1170-0-0301 Side plate dev. (right)
0170-0-0401 Side plate fix. w. shafts (left)
1170-0-0401 Side plate fix. (right)
102 1140-0-3800 Guide bar straight, short
103 1140-0-4500 Guide bar with nose
104 1140-0-3700 Guide bar, curved
105 1170-0-0304 Flat spring 55
106 3079-8-5013 Screw M4x10, A4
107 3009-3-4023 Hexagon nut M4, A4
108 1140-0-0301 PU-roller 35 ground
109 1170-0-0310 Drive shaft rack
110 1101-0-0302 Gear t = 16, D-hole
111 1101-0-0304 Gear t = 32, round hole
112 1101-0-0303 Gear t = 32, D-hole
113 1170-0-0302 Wormgear
114 1101-0-0305 Bearing bush
115 1101-0-0317 Bearing bush, black
116 2014-0-0001 Circlip
117 0170-0-0601 Dryer side plate left w. shafts
1170-0-0602 Dryer side plate right
119 1140-0-0302 Rubber roller 35
120 1140-0-0605 Air jet (35)
121 1170-0-0604 Dryer plate, large
122 1170-0-0603 Dryer plate, small
123 1170-0-0303 Flat spring 35
- 0170-0-0004 Maintenance set
