4 OPTIMAX
®
Technical Specifications
®
Technical Specifications
Film transport:
Continuous roller transport system
Film formats:
In general: Sheet and roll films up to 35.8 cm
(14.1’’) width;
roll films with leader from 70 mm (2.8’’) width;
smallest film format 10x10 cm (4x4’’).
Mammography Type 1171: For processing Mam-
mography Films.
Graphic-Arts Type 1172: With cassette box
(LxWxH) 35x13x12 cm (13.8x5.1x4.7’’) for
processing roll films.
Processing capactiy:
129 films 24x30 cm (10x12“) per hour (standard
model, film fed in crosswise)
Process time:
Standard 90 s
Mammography 135 s
*Option 167 s
Linear speed:
Standard 56 cm/min. (22 in/min)
Mammography 37 cm/min (14.5 in/min)
*Option 30 cm/min (11.8 in/min)
Developer time:
Standard 25 s
Mammography 37 s
*Special 46 s
Tank capacities:
Developer, fixer and washing 5 litres each (1.3 gal)
Circulation system:
Developer and fixer are continiuously circulated by
a circulation pump
Replenishment:
Automatic replenishment by film detection, in rela-
tion to film length
Developer temperature:
Adjustable 28 - 37 °C (82.4 - 98.6 °F)
Fixer temperature:
Adjusted to developer temperature by heat
exchanger.
Water connection:
Permissible water pressure 2 - 10 bar
(29 - 145 psi), permissible water temperature
5 - 30 °C (41 - 86 °F).
Water consumption:
1.9 litres per minute (0.5 gal/min) when process-
ing.
Drain capacity:
7 litres per minute (1.85 gal/min)
Noise level:
Less than 58 dB(A).
Heat emission:
Stand-by: 0.1 kJ/s Processing: 1.4 kJ/s
Environmental condi-
tions:
1) Temperature 18- 40 °C (51,6 - 104 °F), venti-
lated room, room temperature should be lower
than set bath temperature.
2) Relative humidity lower than 80% up to 31 °C
(80 °F), linear decreasing to 50% at 40 °C (104 °F)
3) Height above sea level less than 2000 m
(6666 ft.)
4) Indoor use
Pollution degree:
2
