Protec OPTIMAX - Installation Data

Installation Data
24 OPTIMAX
®
®
Installation Data
77 cm (30.3")
42 cm (16.5")
70 cm (27.6")
75 cm (29.5")
59 cm (23.2")
59 cm (23.2")
Optional working ta-
ble or closed base
cabinet (accessory)
59 cm (23.2“)
75 cm (29.5“)
70 cm (27.6“)
42 cm (16.5“„)
12
4
5
7
3
3
0
c
m
(
1
2
’
‘
)
1
3
0
c
m
(
5
1
’
‘
)
8
5
c
m
(
3
4
’
‘
)
2
0
c
m
(
8
’
‘
)
50cm (20’‘)
60x40cm (24x16’‘)
6
8
Measures and positions are recommendations
Sink
Darkroom
1. Wall socket
220-240 V, 16 Aresp. 110 V,
15 A (depending on machine
model). Power lead should be
equipped with Earth-Leakage
Switch, 25 A / 30 mA nominal
error-current. In addition, a
power control switch can be
installed.
2. Fresh water connection 3/4”
with stop cock, permissible
pressure 2-10 bar, water tem-
perature 5-25 °C.
3. Drainage plastic pipe (PVC)
∅ 50 mm (2“) incl. syphon.
4. Drainage resp. collecting con-
tainers for used developer.
5. Drainage resp. collecting con-
tainers for used fixer.
6. Storing space for replenish-
ment tanks: Below machine or
externally.
7. Ventilation of darkroom is nec-
essary.
8. Sink with freshwater and flexi-
ble hose. Inner dimensions
minimum (LxWxH)
60x40x30 cm (24x16x12“).
20 cm (8“)
130 cm (51“)
85 cm (34“)
60x40 cm (24x16“)
50 cm (20“)
