Model Z9216 Test Performance Record
Serial #: Date:
Tested By:
Equipment Used:
Model#:
RH %: Temperature:
Notes:
FUNCTIONAL TESTS
Test Values
Pass Fail
Front Panel Test
Self Test
Drive Voltage
Resistance Test 24.9 Ω +/- 0.15%
402 Ω +/- 0.15%
6.34 kΩ +/- 0.15%
100.0 kΩ +/- 0.15%
Capacitance Test 22 nF
FREQUENCY ACCURACY
Test Frequency
Minimum Actual Maximum
100 Hz +/- 0.01% 99.99 Hz 100.01 Hz
120 Hz +/- 0.01% 119.99 Hz 120.01 Hz
1 kHz +/- 0.01% 999.90 Hz 1000.1 Hz
10 kHz +/- 0.01% 9999.0 Hz 10001.0 Hz
100 kHz +/- 0.01% 99990.0 Hz 100010.0 Hz
AMPLITUDE ACCURACY
Amplitude
Frequency Minimum Actual Maximum
1.0 V
rms
+/- 2.0% 1 kHz 0.98 V
rms
1.02 V
rms
1.0 V
rms
+/- 2.0% 100 Hz 0.98 V
rms
1.02 V
rms
1.0 V
rms
+/- 2.0% 120 Hz 0.98 V
rms
1.02 V
rms
1.0 V
rms
+/- 2.0% 10 kHz 0.98 V
rms
1.02 V
rms
1.0 V
rms
+/- 2.0% 100 kHz 0.98 V
rms
1.02 V
rms
0.25 V
rms
+/- 2.0% 1 kHz 0.245 V
rms
0.255 V
rms
0.1 V
rms
+/- 2.0% 1 kHz 0.098 V
rms
0.102 V
rms
Internal Bias
2.0 VDC +/- 2.0% 1.96 VDC 2.04 VDC
