Protek Z9216 - Page 52

IMPEDANCE ACCURACY
Minimum Actual Maximum
1.000 KΩ +/- 0.02% 999.3 Ω 1000.7 Ω
RESISTANCE ACCURACY
Resistance
Range Conditions Minimum Actual Maximum
Pass/Fail
10.0Ω 3
1kHz, Series
25.0Ω 3
1kHz, Series
25.0Ω 3
10kHz, Series
25.0Ω 3
100kHz, Series
100.0Ω 3
1kHz, Series
100.0Ω 2
1kHz, Series
400.0Ω 2
1kHz, Series
2
10kHz, Series
400.0Ω 2
100kHz, Series
1.600KΩ 2
1kHz, Parallel
1.6000 KΩ 1
1kHz, Parallel
6.4000 KΩ 1
1kHz, Parallel
6.4000 KΩ 1
10kHz, Parallel
6.4000 KΩ 1
100kHz, Parallel
25.0000 KΩ 1
1kHz, Parallel
25.0000 KΩ 0
1kHz, Parallel
100.0000 KΩ 0
1kHz, Parallel
100.0000 KΩ 0
10kHz, Parallel
400.0000 KΩ 0
1kHz, Parallel
* If the Q Value is Greater Than 0.1, the allowed tolerance must be multiplied by (1+Q).
400.0Ω
CAPACITANCE ACCURACY
Capacitance Frequency Range Minimum
Actual
Maximum Pass/Fail
1.0 nF 1 kHz 0
1.0 nF 10 kHz 1
1.0 nF 100 kHz 2
10.0 nF 100 Hz 0
10.0 nF 1 kHz 1
10.0 nF 10 kHz 2
10.0 nF 100 kHz 2
100.0 nF 100 Hz 1
100.0 nF 1 kHz 2
100.0 nF 10 kHz 2
100.0 nF 100 kHz 3
1.0 µF 100 Hz 2
1.0 µF 1 kHz 2
1.0 µF 10 kHz 3
10.0 µF 100 Hz 2
10.0 µF 1 kHz 3
4
8
