Proteus PSS-515C - Stack Shroud Assembly

20
REMOVE & FASTEN BACK
BOLTS ( 1 ) & WASHERS ( 13 )
S-c ( M8 x 12 )
S-d
S-b
S-a
S-a
F
S-d
S-c ( M8 x 12 )
STUDIO - 5 HOME GYM
TOP TUBE ( A )
REMOVE & FASTEN BACK
BOLTS ( 1 ) & WASHERS ( 13 )
S-d
S-b
S-a
F
S-d
STUDIO - 5 HOME GYM
TOP TUBE ( C )
S-c ( M8 x 12 )
S-b
S-c ( M8 x 12 )
S-a
STACK SHROUD ASSEMBLY
1. REMOVE BOLTS ( 1 ) AND WASHERS ( 13 ) FROM THE ATTCHMENTS OF SLIDER
TUBES ( F ) TO BOTH BASH BASE ( C ) AND TOP TUBE ( A ) , THEN.
ASSEMBLE WEIGHT SHROUD BRACKETS ( S - b ) , ONTO BOTH BASE TUBE ( C )
& TOP TUBE ( A ) , RE - FASTEN THE BOLTS ( 1 ) AND WASHERS ( 13 ).
2. ASSEMBLE WEIGHT SHROUD ( S - a ) ONTO WEIGHT BRACKET ( S - b ) , FIX
BOLTS ( S - c ) AND WASHERS ( S - d ).
PSS515C/520C20020527GB
