CARTON # 1 PARTS IDENTIFICATION LIST
PARTS DESCRIPTION Q'TY
A TOP BRACE TUBE 1
B MAIN SUPPORT TUBE 1
C BASE TUBE 1
D SIDE STABILIZER - LEFT 1
D1 SIDE STABILIZER - RIGHT 1
E REAR STABILIZER 1
F WEIGHT SLIDER TUBE 2
I SEAT ADJUSTABLE TUBE 1
J LEG DEVELOPER 1
N SEAT PAD 1
O BACKREST PAD 1
AA LAT PULL BAR 1
FF 1" FOAM GRIP x 230mm 2
GG 1" FOAM GRIP x 150mm 4
NN ANKLE CUFF 1
QQ HEEL RAISE BELT 1
BEFORE ASSEMBLY
1. AFTER OPENED THE CARTON, CHECK ALL PARTS/COMPONENTS ACCORDING TO
THE PARTS LIST. MAKE SURE ALL PARTS/COMPONENTS ARE PRESENT
CORRECTLY BEFORE ASSEMBLY.
2. DO NOT FIRM TIGHTEN ALL BOLTS/NUTS UNTIL THE MACHINE IS FULLY
ASSEMBLED.
BOLT LENGTH INDICATOR
NOTE : BOLT LENGTHS ARE MANUFACTURED IN METRIC ( MM ) SO IMPERIAL
LENGTH ( INCHES ) IS APPROXIMATE. EG. 65mm = 2 - 1/2"
IN - LINE WITH UNDERSIDE OF HEAD
mm
inch
