Protocol VIDEODRONE FX - Parts

PARTSPARTS
DRONE
1. Canopy
2. Blade Guard
3. Blade
4. Battery Compartment
5. Camera
2
3
REMOTE
1. 2.4G Antenna
2. Power Switch
3. Trim Forward/Backward
4. Flip 360°
5. Forward/Backward
6. Bank Left/Right
7. Video
8. Photo
9. Trim Bank Left/Right
10. Indicator Light
11. Trim Turn Left/Right. The button on this unit is disabled
as it was upgraded to auto trim for left/right turns.
12. Throttle
13. Turn Left/Right
14. Hi/Med/Lo Speed Mode Selector
