Protool CSP 55-2 Original Instruction

11
GB
Hand Circular Saw CSP 55-2
– original instruction
Table of contents
1 Symbols ................................... 11
2 Tool Specifi cations ...................... 11
3 Operating Controls ..................... 11
4 Intended Use ............................. 12
5 Notes on Safety Prevention ......... 12
5.1 General Safety Instructions ......... 12
5.2 Safety Rules for Circular Saws ..... 12
5.3 Additional Safety Rules
for all Circular Saws ................... 12
5.4 Specifi c Safety Rules
for CSP 55-2 Circular Saws .......... 13
5.5 Emission levels .......................... 14
6 Commissioning and Operation ...... 14
7 Adjustment ............................... 15
7.1 Cutting Depth Adjustment ........... 15
7.2 Cutting Angle Adjustment ........... 15
7.3 Cutting Edge Indicator ................ 15
7.4 Parallel Guide ............................ 15
7.5 Dust Extraction .......................... 15
7.6 Replacing the Saw Blade ............. 15
8 Operating Instructions ................ 16
9 Maintenance .............................. 16
10 Environmental Protection/
Disposal.................................... 16
11 Warranty .................................. 17
12 Declaration of Conformity ............ 17
1 Symbols
Double insulation
Warning of general danger
Risk of electric shock
Wear ear protection!
Wear a dust mask!
Use protective gloves!
Read the instructions
Not to be included in municipal refuse
► Advice or tip
2 Tool Specifi cations
Nominal voltage 230 V ~
Mains frequency 50 / 60 Hz
Power consumption 1050 W
Rated rpm (no load) 4700 min
–1
Saw blade Diameter 160 mm
Hole 20 mm
Tooth width 2.8 mm
Blade thickness 1.8 mm
Cutting depth 90° 0 … 55 mm
45° 0 … 38 mm
Cutting angle 90° … 45°
Weight (without accessories) 3.6 kg
Protection class II /
3 Operating Controls
[1-1] Lock-off switch
[1-2] On/Off switch
[1-3] Sawdust ejector / Connection neck
for dust extraction
[1-4] Riving knife screw
[1-5] Lever for swinging guard
[1-6] Base plate
[1-7] Swinging protective guard
[1-8] Grip
[1-9] Winged screw for cutting angle
adjustment
[1-10] Winged screw for parallel guide
[1-11] Cutting mark
[1-12] Winged screw for cutting depth
adjustment
[1-13] Scale
[2-1] Parallel guide
[2-2] Allen key
[2-3] Ring spanner
[2-4] Clamping screw
[2-5] Washer
[2-6] Clamping fl ange
[2-7] Saw blade
[2-8] Mounting fl ange
[2-9] Riving knife
[2-10] Motor spindle
Not all of the accessories illustrated or de-
scribed are included as standard delivery.
