Proxim ORiNOCO AP-9100 - Antenna Specifications

Hardware Specifications
ORiNOCO
®
802.11n & 802.11ac Access Points - Hardware Installation Guide 43
3.3.1 Antenna Specifications
Weight 0.400 kg (0.88 lbs)
Environmental
Operating Temperatures:
0 to 40ºC (32ºF to 104ºF)
Storage Temperature:
- 20º to 60ºC (-4ºF to 140ºF)
Humidity
(non-condensing)
5% ~ 90% typical
MTBF
>500,000 hrs
Power
Consumption
< 12.9 watts
Warranty One year parts/labor
Feature Specification
Frequency Range
2.400 GHz - 2.484 GHz 5.150 GHz – 5.850 GHz
Peak Gain
4.46 dBi 5.0 dBi
VSWR
2.0 : 1 2.0 : 1
Isolation (db)
> 25
Impedence
48 Ohms
Max.Power
2 Watts
Weight
10 g
Connector
IPEX
Cable Length (mm)
100~180
Dimension (mm)
90 x 90 x 10
