802.11n & 802.11ac Access Points - Hardware Installation Guide 9
2
Hardware Overview and Installation
2.1 Device Operational Modes
: The operational mode ‘g/n’ is backward compatible to mode ‘b’.
This chapter covers the hardware overview and installation procedures of the following products:
• ORiNOCO
®
AP-800 and AP-8000
— Hardware Overview
— System Requirements
— Product Package
— Installation Procedure
• ORiNOCO
®
AP-8100
— Front View of the Device
— Rear View of the Device
— System Requirements
— Product Package
— Installation Procedure
• ORiNOCO
®
AP-9100
— Front View of the Device
— Rear View of the Device
— System Requirements
— Product Package
— Installation Procedure
Device Type Operational Mode (With Supported Frequency Band)
Radio 1 Radio 2
AP-800 802.11b/g/n (2.4 GHz) Not Applicable
AP-8000 802.11a/n (5 GHz) 802.11b/g/n (2.4 GHz)
AP-8100 802.11a/n (5 GHz) 802.11b/g/n (2.4 GHz)
AP-9100 802.11a/n/ac (5 GHz) 802.11b/g/n (2.4 GHz)
:
• All the interface (radio) 2 parameters discussed in this chapter are applicable only to a dual-radio
device.
• For a quick reference on how to install and mount the device, please refer to the ORiNOCO
®
AP-800,
AP-8000, AP-8100 and
AP-9100 Quick Installation Guides respectively.
