ing and toymanufacture.Forthis reason, it is precisely the right tool
fordesigners, architects (modelbuilding) and carpenters.
The large-area, saw table 9 formitre cutscan be titledupto 45°, is
manufacturedfromaluminium die casting for the highest precision
and stability, and is then ground for optimal glide properties.
The arrangement of the sawblade holders item 2 and 10 allow the
use ofbothsaw bladeswithand without cross pin depending on the
area ofapplicationand the ma terial of the tool. In the Proxxon
accessoriesrange youwill find the corresponding sawbladesforthe
respective task.We recommend that youuse only Proxxonsaw blades!
The replacement sawbladesare storedinthe “sawblade garage"
12, on the side of the panelling of the toparm.
The DSH saws soft woodupto a thickness of 50 mm, plastic up to
30 mm and non-ferrous metals up to 10 mm.
The sawcan also be usedwithout problemforsepara ting Plexiglas,
GRP, foam, rubber, leatherand cork.
And so that the dust doesnot obscure the view of the cutting line
whenworking, there are automatically drivenbellows withadjustable
air nozzle 8.Anadditional vacuum cleanercan also be connected.The
connecting piece 13 is
positionedat 90° to save space.
This guaranteesclean work.
5 Technical data
No. ofstrokes:900 or 1400/min
Stroke height: 19 mm
Max. cutting depth:50 mm
(in wood) at 45°: 25 mm
Cutting blade length:127 mm (withcross pin)
125-130 mm (without cross pin)
Noise development: < 70 dB(A)
Vibration:<2.5 m/s
Measurements:
LxBxH:53 x 27 x 33 (in cm)
Table: 360 x 180 mm
Sawframe radius:400 mm
Motor:
Voltage: 220/240 Volt, 50/60 Hz
Powerconsumption:145/205 W
Foruse in dry environments only
Please do
not dispose off the machine!
6Set-up and commissioning of the saw
6.1 Unpacking (fig. 1a and 1b)
1.Unpack the device and remove it from the box. Ensure that the de-
vice is not liftedbythe plastic panelling around the toparm 16.
2.For transport reasons, the saw table 9 is foldedupat an angle of
about 45°.Turn the toggle 6 to tilt the table back into the horizon-
tal position (the precise setting is describedbelow).Thenclose the
toggle 6 again.
6.2 Setting up the saw
Note:
Safe and precise work is only possible withcareful fixing!
1.Secure sawwithtwo screws (Ø 6 mm, not includedinscope ofde-
livery) onasolid workbench. Use the drill holesintendedforthis
purpose (11, fig. 1) which are locatedat the front and back of the
sawbase.
6.3 Adjust and set angle display (fig. 2)
1.Slightly loosen toggle 1 (fig. 2) and fold saw table 2 up to stop
screw 3.
2.Clampsaw blade 4! See the corresponding section 6.7.1 of these
instructions. Caution! Mains plug must not be connected.
3.Using an angle 5 on the saw table 2, check the right-hand angle
to the sawblade.The stopscrewispreset.Ifthis still has to be ad-
justed, youcan adjust the setting yourself using an Allenkey7, as
shown in fig. 2, once the counternut has beenloosened.Aftercor-
rect setting, tighten the counternut.Make sure that the stopscrew
doesnot go out ofpositioninthis process.
4.Check the “zero”setting of the indicator 8,
if necessary, correct af-
ter the fastening screwhas beenloosened. Forprecise working,
carry out sawing sample.
5.Saw asample fromapiece ofwoodand check the angle again, if
necessaryadjust the saw table 2, indicator 8 orstopscrew 3 as
shown in fig. 2.
6.4 Assembling the air nozzle (fig. 3)
1.Take partsforsecuring the air nozzlesfromthe bag.
2.Screw the knurledscrew 1 withclamping pieces 2 into the sawframe.
3.Introduce the air nozzle pipe 3 into the hole on the openedclamp
pieces, adjust the pipe and slightly tighten the toggle 1.
4.Place the air hose 4 onpipe 3 and nipple 5.
6.5 Saw blade guard
Caution!
The scope ofdelivery
ofyour scroll sawincludesasaw blade guard.
This is simply mountedinthe upperplastic cover of the sawarm.
Fig. 3ashows how to assemble the sawblade guard. Bothpins at the
sawblade guard are clippedinto the designateddrill holes. Please
note that the sawblade guard is an important safety tooland the saw
may not be opera tedwithout it! Injuriescould be the result.
The following describesactivitiesinwhich the guard may be disas-
sembled expediently. But it must be clearly noted that the sawblade
guard must be mountedagain when this work is completed: Opera-
tionwithout this important safetyaccessory is not permitted!
Further graphics in these instructions sometimesshowthe device
without asaw blade guard. This only servesasoptical clarification of
the illustratedactions and is in no way intended to convey that the
machine may be opera tedwithout the sawblade guard!
- 14 -
