8.3. Changing the rubber rings on the wheels
Each wheel is covered with a rubber ring to protect
the saw blade. These rubber rings are wear items and
must be replaced whenever necessary. The rubber
rings must therefore be examined regularly. In case of
a ‘hollow shape’ caused by abrasion (fig. 19), the
respective ring must be replaced immediately.
1. Cut the worn rubber ring (fig. 20) by using a sharp,
heated knife.
2.Warm up the new rubber ring for 10 minutes in hot
water (not boiling).
3.Press the plastic ring firmly onto the wheel, until it
sits perfectly in the groove.
Install the wheel and the housing cover and fasten it
with the 4 socket head cap screws.
8.4. Care and cleaning of the machine
W
arning!
Always disconnect the mains plug prior to cleaning
and maintenance operations.
If any part is missing or damaged, do not plug the
MICRO Band Saw in until the missing or damaged
part is replaced, and assembly is complete. To avoid
electrical shock, use only identical replacement parts
when servicing double insulated tools.
To avoid fire or toxic reaction, never use gasoline,
naphtha, acetone, lacquer thinner, or similar highly
volatile solvents to clean the MICRO Band Saw.
Do not allow brake fluids, gasoline, or penetrating oils
to come in contact with the plastic parts. They contain
chemicals that can damage or destroy plastics.
Turn switch OFF and always remove plug from power
source before making any adjustments or repairs.
All electrical or mechanical repairs should be done
only by qualified service technicians.
When servicing use only PROXXON replacement
parts. Use of any other parts may create a hazard or
cause product damage.
Any attempt to repair or replace electrical parts on this
MICRO Band Saw may create a hazard unless repair
is done by a qualified service technician. Repair serv-
ice is available at your PROXXON service center (You
find the address on the back of this manual)
•After working with the machine remove all chips
with a suitable hand broom, a vacuum cleaner, a
brush or compressed air— do not use your hands.
Turn off the machine before cleaning.
•Clean the machine regularly with a cloth from all dirt.
9. Optional Accessories
Note:
Use accessories and spare parts that have been rec-
ommended by PROXXON. Improper accessories may
be hazardous!
NO 28 187Blade guide
Triple ball bearing system with feed pipe
for coolant when used with the diamond
blade. Can also be used in conjunction
with normal blades.
Liquid coolant kit for MBS/E:
For wet cutting and finishing of glass, stones and tiles.
NO 28 188 Coolant container:
Plastic container with stopcock, 39" (100 cm)
tubing, 2 nipples for the MBS/E table and
mounting bracket/screws. Holds 1 quart.
NO 28 189 Coolant collection tray
Size 16
17
/ 32" x 12
13
/ 64 " x
19
/ 32"
(420 x 310 x 15 mm). Includes gasket for
sealing the attachment holes of the
machine. With 19
11
/ 16 " (50 cm) discharge
tube and nipple for band saw table. The
tray is undrilled and may so be used on
other machines, too.
10. Accessory Blades
NO 28 174Swedish steel 42" x
13
/ 64 " x
1
/ 64 " (1,065 x
5 x 0.4 mm). Fine toothed (24 TPI). For
steel and brass.
NO 28 176 Swedish steel, same size, but coarse
toothed (14 TPI). For wood and plastics.
NO 28 180Special tempered Swedish steel with
induction-hardened teeth. Extra narrow for
tight curves 42" x
9
/ 64 " x
1
/ 64 " (1,065 x 3.5
x 0.5 mm). Coarse toothed (14 TPI). For
aluminum and plastic.
NO 28 186Diamond blade
For stones, ceramics, glass and fiberglass.
42" x
7
/ 64 " x
1
/ 64 " (1,065 x 3 x 0.3 mm).
The cutting of glass and ceramics should
only be attempted in conjunction with the
optionally available coolant system. See
for details above (Point 9)!
- 11 -
