10.2 Wiring diagram
Figure 7 indicates the electrical connections for standard actuators. The wiring diagram inside the actuator is binding
for the specific actuator wiring. For any optional accessories, see the separate wiring diagram in the corresponding
installation instructions.
*optional
Figure 7: Electric supply
PE earth connection has to be connected to gear casing at !
