10. Signalisation / functions
10.1 DIP switch
S1
Function
1 2 3 4 5 6 7 8
Signal set value position feedback
Voltage On On Off Off Off On Off On
Current Off Off On On On Off On Off
1)
“Open with force” refers solely to automatic commissioning. During operation the actuator will stop at the found position
-> see chapter 11. Operation
2)
After changing the switches S2-3 and S2-4, perform re-calibration to activate the new operating mode.
S2
Function
1
2
3
2)
4
2)
5
6
Control via analogue set value On
Control via binary inputs Off
Extend valve stem with increasing set value On
Retract valve stem with increasing set value Off
Automatic
commis-
sioning
Close with force / Open with force
1)
On On
Close with force / Open with 20 mm stroke On Off
Close with force / Open with 30 mm stroke Off On
Close with force / Open with 40 mm stroke Off Off
Manual
Commis-
sioning
Close with force / Open with required stroke On On
Set value range / feedback signal: 0-10 V / 0-20 mA On
Set value range / feedback signal: 2-10 V / 4-20 mA Off
Cut-off by force if valve stem is in extended position On
Cut-off by force if valve stem is in retracted position Off
