16
16. Appendix
16.1 Accessories
Various accessories are available in order to adapt the actuator to the various installation conditions. The following
shows a short selection.
Please see the actuator data sheets for technical data. Operating and installation instructions are available
separately for each accessory. We will be pleased to assist you with advice also by telephone.
• =
available
)
1
= PSAP with external relay required
)
2
= only to be used with reversing starter contactor
)
3
= supply voltage 24 V or 115-230 V
For additional position and torque switches:
Standard switches with silver contacts are suitable for currents 100 mA to 5 A at voltages in the
range of 24 V to 230 V AC/DC. For lower power up to 0,12 VA (0,1 mA to 100 mA at 1 V to 24 V
AC/DC) we recommend switches with gold contacts (2WE Gold and 2DE Gold).
With power supply 24 VAC the open motor phase can produce voltages up to 35 V due to motor
generated induction voltage.
Accessories/
options
Power supply 230 VAC 1~ 115 VAC 1~ 24 VAC 1~ 400 V 3~ 24 VDC
Position signal
switches 2WE
• • • • •
Position signal
switches gold
2WE
Gold
• • • • •
Add'l torque switches 2DE
• • • • •
Add'l torque switches
gold
2DE
Gold
• • • • •
Positioner PSAP
• • )
1
• )
1
• )
2
Position transmitter PSPT
• • • • •
Heating resistor HR
• • • •)
3
•
Potentiometer PD
• • • • •
Reversing starter
contactor
WSM01
•
Corrosion protection K2
Corrosion protection K2 incl. heating resistor
Enclosure IP67 IP
IP68 incl. heating resistor and corrosion protection K2
