28
POSITIONING THE APPLIANCE
For a safe and quiet operation, the furnace must be levelled in both directions. Give each “U” shape
block, an equal support so that the weight is evenly distributed.
PIPE CONNECTOR AND DAMPER
The pipe connecting the furnace to the chimney must be as short as possible. Whenever possible, the
use of 45
o
elbows is recommended for a better evacuation of the smoke in the chimney, for both the wood
burning furnace and the oil burning unit (UH). The barometric damper provided with the appliance must be
installed in the oil unit evacuation pipe, approximately 24" from the flue outlet of the oil unit.
TYPE OF FURNACE
(UH) OIL
UNIT FLUE
PIPE DIAMETER
PSG/UH 2000
5”
PSG/UH 3000
5”
PSG/UH 4000
5”
PSG/UH 4500
6”
