Connect the Battery
Do not connect the battery until the system is ready to be plugged in
and tested, after all AI devices are installed and wired.
1. Slide the black negative battery wire onto the negative pole of
the battery.
2. Slide the red positive battery wire onto the positive pole of the
battery.
Battery Maintenance and Replacement Instructions:
The battery supplied with the controller is a maintenance-free battery.
When the battery needs to be replaced, the system will alert the
administrator. To replace the battery:
1. Remove the positive and negative battery terminals.
2. Remove the old battery and replace with a new battery of the
same type and rating using the connection directions above.
3. Dispose of the old battery per local codes for hazardous waste.
Plug in the Power
Do not plug in the power until after all AI devices are installed and
wired and the system is ready to be plugged in and tested.
1. Connect the power cord to the small power supply unit.
2. Plug the other end of the cord into a wall outlet.
Power supplies should
be mounted in interior
locations such as maintenance
rooms. Never install a power
supply in an area that will be
inaccessible for maintenance.
