7.3 Menu Parameter Settings
11984 Rev 01 Page 4
SENTRY Supervisor Preset Factory Parameters
(PARAMETERS MAY VARY AND ARE APPLICATION DEPENDENT) Version: G1.9A PRODUCT: INTEL SENTRY 1510
APPLICATION: Negative Process Pressure Control With 2” Transducer
Supervisor
Menu
Default Value
X = Not Applicable
R = Read Only
Change
and Date
Comments
Pres Sp R
Flow Sp X
Pos Sp X
Pressure R
Flow X
Step Cnt R
HouseVac X
Aux In X
Pres Sp1 Exhaust Pressure Set Point Entry.
Pres Sp2 Pres Sp2 - Sp4 are automated test
Pres Sp3 set points for “Cycle Mode” with
Pres Sp4 2 set points or 4 set points
Flow Sp1 X
Flow Sp2 X
Flow Sp3 X
Flow Sp4 X
Pos Sp1 X
Pos Sp2 X
Pos Sp3 X
Pos Sp4 X
Alarms Disable
Dev Band X
Lo Alarm X
Hi Alarm X
Pres FS 5080 Pres. Transducer =50.80 mm WC
Flow FS X
House FS X
Aux FS 5000 Analog Input Full Scale definition for set
point control. Full Scale is 5.000V.
SaveData To: save menu configuration in non-
volatile EEPROM...
1. press *, down arrow to code 0
2. press up arrow to code 77
3. press ENT
BaudRate 9600
Supervisor
Menu
Default Value
X = Not Applicable
R = Read Only
Change
and Date
Comments
HWCtlLck Disable
Ctl Itvl 250
CtrlLock Run
FlowCoef X
FiltRate 2
Ctrl Inv IncDec
Gain 4
GainFine 4
Integral 0
Intg Sum 0
Deriv 0
Deadband 32
Hyst 12
MaxCtlSt 100
StepRate 300
StepRang 3000
Step Lim OFF
Step Req R
Clk Min Clock Day, Hour, Min are user settable.
Clk Hour
Clk WDay
PlotItvl 200
PlotMode Retrace
Plot Sel Pres
Cycle Disable
CyclItvl X
StptMode Single Use “Single” for set point entered by key
pad or for Serial interface. Use “Analog”
for analog set point control.
OperMode Pres
CtrlMode Cls_Lp
ResetAct OFF
Disp #0 Sentry Ver
Disp #1 Pres SP
Disp #2 Pres
