NORMI 13 (T42023)
Operating Manual - Preparing the Constancy Test
D703.131.00/03 en 17
4
5
6
7
8
2
3
1
Figure 3: Schematic test setup with PMMA absorber (near image receptor)
1
Additional, optional copper plate, 1.3 mm
thick, for measurements at 100 kV
2
Supporting plate (patient couch)
3
Entrance plane of the image receptor
4
X-ray tube
5
Collimator
6
NORMI 13 test object (consisting of structure
plate and 1 mm copper plate)
7
PMMA absorber, 30 mm
8
Anti-scatter grid
