4.2 Use of the Wall Stand Holder T20018 with Bucky Mounting
Device T20005 and Test Object
Assembly
•
Place the wall stand holder T20018, the test
object, and the bucky mounting device T20005
on a suitable table.
•
Fasten the rails of the wall stand holder
T20018 to the bucky mounting device T20005
(refer to Figure 8).
•
Set the angle bracket for fitting the bucky
mounting device to the thickness of the wall
bucky.
•
Insert the test object in the wall stand holder.
Using the set screws (3, Figure 7), press the
test object against the rails.
HINT
For further use, please remember that the test
object and the holder are not firmly joined.
•
Using a ruler or the edge of the table, align the
height of the test object in the mounted holder.
•
Holding the assembled holder with both
hands, suspend it in the wall bucky. It may
prove necessary to adjust the position of the
bucky mounting device.
Disassembly
•
Holding the assembled holder with both
hands, lift it off the wall bucky. To further disas-
semble the holder, place it on a suitable table.
•
Undo the set screws (3, Figure 7) and remove
the test object.
