PAGE 22
PART NO.
QTY.
ITEM NO.
DESCRIPTION
245 REV.110110
Refer to PAGE 28 for ASSEMBLY DRAWING.
103 1 25095 BALL BEARING #6020
400 1 20095 PLANET HUB
410 3 21169 PLANET PIN
411 3 25060 CIRCLIP ROTOR CLIP C-62
412 3 21176 INTERNAL GEAR STOPPER
413 3 25119 CIRCLIP ROTOR CLIP SH-62
420 3 20101 PLANET GEAR
421 6 25064 THRUST WASHER TORRINGTON # TRA 1018
423 3 25269 NEEDLE BEARING TORRINGTON # BH1016
430 1 21174 INTERNAL GEAR
440 1 20178 SUNGEAR
444 1 19036 SUNGEAR STOPPER
509 1 25150 BALL BEARING #6022
515 1 25151 OIL SEAL
600 1 21209 CONNECTING SHAFT
601 1 25734 O-RING - 234 3" ID 1/8" CS
602 1 20035 RETAINING RING
603 1 25232 NEEDLE BEARING TORRINGTON # B2012
607 1 26025 OIL SEAL
615 2 25105 THRUST WASHER TORRINGTON #TRB 2031
617 1 25733 THRUST BEARING TORRINGTON # NTA 2031
700 1 21358 BRAKE HOUSING
703 1 25331 PLASTIC CAPLUG 3/4 NPT THREADED
707 1 25192 O-RING -173 8-1/2" ID 3/32" CS
712 1 21208 BRAKE SPACER
714 7 21252 DIVIDER PLATE
715 6 25194 FRICTION PLATE
717 2 25729 SUPPORT WASHER ANDERTON # R.28/40/2.0
719 1 25111 CIRCLIP ROTOR CLIP SH-125
720 1 21206 BRAKE HUB
722 1 21193 SPRAG CLUTCH ALIGNER
723 2 25187 SPRAG CLUTCH
724 1 21193 SPRAG CLUTCH ALIGNER
727 1 25492 CIRCLIP ROTOR CLIP SH-106
730 1 21205 MOTOR DRIVE SHAFT
731 1 25500 CIRCLIP ROTOR CLIP C-93
750 1 20262 PISTON
751 1 25190 O-RING -90 DURO -171 8" ID 3/32" CS
752 16 20028 BRAKE SPRING
753 1 25191 O-RING -90 DURO -267 8-1/4" ID 1/8" CS
23123 WINCH SEAL KIT, CONSISTS OF ITEMS:
105, 123, 515, 601, 607, 707, 751, 753 AND 801
PARTS REFERENCE - BRAKE GROUP
