PAGE 29
PARTS REFERENCE
REF. NO.
DESCRIPTION
QTY.
PART NO.
606 21086 1 BACK-UP WASHER
607 25345 1 OIL SEAL DEAMAR 175225312 HP3
700 23775 1 BRAKE HOUSING
701 23838 1 PRIMARY HOUSING
703 25557 1 PLASTIC CAPLUG SAE #20 ORB
707 25286 1 O-RING -277 11-1/2"ID 1/8"CS
708 25339 1 O-RING -278 12"ID 1/8"CS
712 23837 1 BRAKE SPACER
713 25305 7 DIVIDER PLATE
715 25304 6 FRICTION PLATE
718 ** 1 SUB-ASSEMBLY BRAKE HUB
744 25890 2 LOCKWASHER 7/8"
745 22613 2 CAPSCREW - HEX HEAD 7/8 - 9NC X 1 LONG
750 20397 1 PISTON
751 25343 1 O-RING -90 DURO -451 11"ID 1/4" CS
752 20413 20 BRAKE SPRING #4G 5C 2.270 X 1.230
753 25342 1 O-RING -90 DURO -452 11-1/2"ID 1/4"CS
800 23779 1 MOTOR ADAPTOR
801 25032 1 PIPE PLUG 1/2 NPT SOC STEEL, AIRWAY #5409-8
802 25772 2 CAPSCREW - SOCKET HEAD 3/8-16 UNC X 1.00" GR.5
803 25298 2 LOCKWASHER 3/8" HIGH COLLAR
819 25136 1 O-RING -159 5"ID 3/32" CS
850 26639 1 MOTOR -191 (3" GEAR)
852 26610 1 HOSE ASSY 1/4"ID #4JIC STRT #4JIC 90‘ -15"LG
853 ** 1 TUBE 90 ELB #4 JIC X #6 ORB; AIRWAY 6801-4-6
854 26643 1 SANDWICH GAGE BLOCK 2" (CODE 61) ORB#6
856 25972 1 PLUG - SAE #6 ORB SOC HEAD AIRWAY 6409-6
858 26439 ** TUBE CONN #4 JIC X #6 ORB; AIRWAY 6400-4-6
859 26644 1 O-RING -228 2-1/4" ID 1/8"CS
860 ** 1 SHUTTLE VALVE
861 ** 1 UNION #6 ORB X #6 ORB
862 ** 1 PLASTIC CAPLUG SAE #6 ORB
929 25536 1 PLASTIC CAPLUG SAE #12 ORB
955 25559 2 PLASTIC CAPLUG 2.0" DAEMAR T-21
* THESE PARTS VARY ACCORDING TO DRUM CODE, REFER
TO APPENDIX A.
** THESE PARTS VARY ACCORDING TO BRAKE CODE, REFER
TO APPENDIX B.
354 REV.030819
