PAGE 20
PARTS REFERENCE - FINAL DRIVE
PART NO.
DESCRIPTION
100 1 20399 FINAL HOUSING
103 1 25332 BALL BEARING # 6024
104 1 20460 BEARING RETAINER
105 1 26359 OIL SEAL
120 1 21815 END COVER
121 2 25237 PIPE PLUG 3/4 - 14 NPT
122 1 19036 SUNGEAR STOPPER
123 1 25340 O-RING -281 15" ID 1/8" CS
124 1 20416 RETAINING RING
126 1 20418 PLANET HUB STOPPER
130 1 20677 BREATHER RELIEF ASSEMBLY
300 1 20398 PLANET HUB
310 3 20406 PLANET PIN
311 3 25199 CIRCLIP ROTOR CLIP SH-168
313 3 25199 CIRCLIP ROTOR CLIP SH-168
320 3 20405 PLANET GEAR
321 6 25167 THRUST WASHER TORRINGTON # TRB 2840
323 72 25297 LOOSE ROLLER TORRINGTON #G613 - Q
340 1 * SUNGEAR
343 1 25242 CIRCLIP ROTOR CLIP SH-206
500 1 * CABLE DRUM
502 1 20423 CABLE ANCHOR
503 1 25032 PIPE PLUG 1/2 - 14 NPT
513 1 25337 CIRCLIP ROTOR CLIP SH-475
550 1 * BASE
551 28 25346 CAPSCREW - HEXHEAD 5/8 - 11NC X 1.75 GRADE 5
552 1 * BASE
553 28 25359 LOCKWASHER 5/8"
* These part numbers vary according to drum code.
Refer to APPENDIX B.
Refer to PAGE 22 for winch seal kit and PAGE 28 for ASSEMBLY DRAWING.
249 REV.110817
ITEM NO.
QTY.
