PAGE 24
DESCRIPTION
249 REV.970901
537 12 25081 CAPSCREW - HEX HEAD 1/2 - 13 NC X 1.5 GRADE 5
541 12 25014 LOCKWASHER 1/2"
730 1 20415 MOTOR DRIVE SHAFT
731 1 25288 CIRCLIP ROTOR CLIP C-112
800 1 20401 MOTOR ADAPTOR
801 3 25127 O-RING -013 7/16" ID 1/16" CS
802 1 * *
805 2 25040 PIPE PLUG 1/8 - 27 NPT
806 1 * *
807 1 * *
809 1 * *
813 1 25031 PIPE PLUG 1/4 - 18 NPT
861 1 25350 GEAR HOUSING -086 COMM. #316 8230 241
865 4 25356 DOWEL PIN COMM. #391 2082 033
869 2 25348 SEAL - GASKET COMM. #391 2884 024
870 1 21761 PORT END COVER
875 4 25352 BEARING - ROLLER COMM. #391 0381 060
877 2 25646 SEAL - RING COMM. #391 2585 023
881 1 25645 GEAR SET -086 COMM. #316 2830 007
885 2 25644 THRUST PLATE COMM. #391 2185 053
887 4 25647 SEAL - TEFLON COMM. #391 2885 040
899 2 25031 PIPE PLUG 1/4 - 18 NPT
929 1 * *
950** 1 * SUB - ASSY MOTOR -086 COMM. WM76
951 8 25357 CAPSCREW - HEX HEAD 5/8 X 6.75 GRADE 5
953 8 25325 WASHER COMM. #391 3784 028
955 2 25559 PLASTIC CAPLUG 2.0"
23117 MOTOR SEAL KIT, CONSISTS OF ITEMS:
869, 877 AND 887
* These part numbers and descriptions vary according to brake code.
Refer to APPENDIX C.
** ITEM 950, MOTOR SUB-ASSY CONSISTS OF ITEMS:
800, 802, 805, 806, 807, 809, 813, 861, 865, 869, 870,
875, 877 881, 885, 887, 899, 929, 951, 953 AND 955
QTY.
ITEM NO. PART NO.
Refer to PAGE 22 for winch seal kit and PAGE 28 for ASSEMBLY DRAWING.
PARTS REFERENCE - MOTOR GROUP
