INSTALLATION DIMENSIONS
BARREL)
POCKET OR ON
IN CABLE ANCHOR
(LOCATED EITHER
1/2-14 NPT
FILLER PORT
C D
H c/c
G
[32]
1.3
S
N
E
M
DIAA
DIAB
[91]
3.6
L
[FREE SPOOL MODELS]
K
ROTATION CLOCKWISE PRESSURIZE FOR
FOR PORT SIZE SEE MOTOR CHART SAE 4-BOLT FLANGE
BREATHER RELIEF VALVE
CLOCKWISE
FOR SAFETY:
[STANDARD MODELS]
J
[MOTOR]
I
P
[31.8]
1.25
F
GAUGE PORTS
1/4-18 NPT
CIRCULATION INLET PORT 3/8-18 NPT (EXTERNAL CIRCULATION MODELS ONLY)
4 MOUNTING HOLES 1 9/32 DIA [32.5] USE O/ 1-1/4 BOLTS GRADE 5 OR BETTER
R c/c
PRESSURIZE FOR COUNTER-CLOCKWISE ROTATION
OPTIONAL EXTERNAL BRAKE RELEASE PORT 1/8-27 NPT
STANDARD CABLE ANCHOR IS SUITABLE FOR 7/16 - 7/8" DIA WIRE ROPE ON 10" DIA DRUM BARREL
CIRCULATION RETURN PORT 1-11 1/2 NPT
FREE SPOOL PORT 1/4-18 NPT
DRAIN PORT 3/4-14 NPT
FILLER PORT 3/4-14 NPT
A MINIMUM OF 5 WRAPS OF WIRE ROPE MUST BE MAINTAINED AT ALL TIMES !
