Pullmaster M12 Series - Page 209

PAGE 28
I1029-1-G
FOR SAFETY: A minimum of 5 wraps of wire rope must be maintained at all times!
253 REV.110124
Standard cable anchor is suitable for 3/4" to 1 1/4" diameter wire rope.
INSTALLATION DIMENSIONS
DRAIN PORT 3/4-14 NPT
[112]
4.4
[140] 5 1/2
[111] 4 3/8
[41]
1.6
M
B
A
H
[67]
2.6
G
C D
BREATHER RELIEF VALVE
I
J
STANDARD GEAR MOTOR SAE 4-BOLT FLANGE SEE MOTOR CHART FOR PORT SIZE
CIRCULATION RETURN PORT 1-11.5 NPT
F
R
S
P
HOISTING
FILL & DRAIN PORT 3/4-14 NPT
GAUGE PORTS 1/4-18 NPT
OPTIONAL EXTERNAL BRAKE RELEASE PORT 1/8-27 NPT
PRESSURIZE FOR COUNTER-CLOCKWISE ROTATION
PRESSURIZE FOR CLOCKWISE ROTATION
CIRCULATION PORT 3/8-18 NPT (EXTERNAL CIRCULATION MODELS ONLY)
4 MOUNTING HOLES 1-7/16 [36.5] 1-7/16 [36.5] GRADE 5 OR BETTER
OPTIONAL FREESPOOL RELEASE PORT 1/4-18 NPT
FILLER PORT 3/4-14 NPT
[32]
1.3
L
STANDARD CABLE ANCHOR IS SUITABLE FOR 3/4" TO 1-1/4" DIA WIRE ROPE
