PAGE 24
APPENDIX A
316 REV.000315
* Performance specifications are based on standard hydraulic motor with 1/2 inch diameter wire rope.
POUNDS
(KILONEWTONS)
DRUM
CODE
CABLE DRUM SIZES
INCHES
(MILLIMETERS)
BARE FULL BARE FULL
BARREL FLANGE LENGTH 1/2 inch 7/16 inch 3/8 inch DRUM DRUM DRUM DRUM
FEET/MINUTE
(METERS/MINUTE)
LUBRICATING
OIL
VOLUME
REQUIRED
U.S.
GALLONS
(LITERS)
LINE PULL
AT MAXIMUM
PRESSURE*
LINE SPEED
AT MAXIMUM
VOLUME*
WIRE ROPE STORAGE
FEET
(METERS)
-1 7.0 11.5 8.0 152 166 227 6000 4091 69 101 0.8
(178) (292) (203) (46) (51) (69) (26.7) (18.2) (21) (31) (3.0)
-2 7.0 13.5 8.0 231 297 375 6000 3462 69 119 0.8
(178) (343) (203) (71) (90) (114) (26.7) (15.4) (21) (36) (3.0)
-4 7.0 13.5 12.0 347 445 562 6000 3462 69 119 1.0
(178) (343) (305) (106) (136) (171) (26.7) (15.4) (21) (36) (3.8)
STANDARD REDUCTION RATIO
