PAGE 4
OPTIONS
CABLE DRUM SIZES:
Aside from the standard drum sizes listed in APPENDIX A, the PULLMASTER Model M8 planetary winch can
be supplied with optional drums to accommodate large wire rope storage capacity.
DRUM GROOVING:
Cable drums for the PULLMASTER Model M8 planetary winch can be grooved. Where this option is a
requirement, it is necessary to state the size of wire rope which is to be used with the winch.
OPTIONAL GEAR SECTION FOR THE HYDRAULIC MOTOR:
The performance of the standard PULLMASTER Model M8 planetary winch can be changed by using different
gear sections. (Contact the factory for performance information.)
HYDRAULIC MOTORS FOR HIGH PRESSURE HYDRAULIC SYSTEMS:
The operating pressure of the PULLMASTER Model M8 planetary winch is limited to 2000 psi (138 bar). For
hydraulic systems operating with a higher range of hydraulic pressure, the winch can be supplied with a hydraulic
piston motor, which will provide for the same basic performance in terms of line pull and line speed capacity.
(Contact the factory for this requirement.)
The PULLMASTER WINCH CORPORATION will consider other options for quantity requirements.
FAILURE TO PROPERLY VENT EXTERNAL BRAKE RELEASE
PORT WILL TRAP BRAKE PRESSURE AND ALLOW THE LOAD
TO DROP, CAUSING PROPERTY DAMAGE, SEVERE INJURY
OR DEATH. WINCHES SUPPLIED WITH EXTERNAL RELEASE
OPTION MUST BE CONNECTED ACCORDING TO TYPICAL
HYDRAULIC CIRCUIT.
COUNTERCLOCKWISE ROTATION:
The drum rotation of the standard PULLMASTER Model M8 planetary winch is clockwise for hoisting when looking
at the hydraulic motor of the winch. Drum rotation for counter clockwise hoisting direction is available as an option.
EXTERNAL BRAKE RELEASE:
PULLMASTER planetary winches can be supplied with an external brake release which permits release of the
automatic disc brake from an external pressure source.
247 REV.980215
DANGER
